ZS44/ZS56 Headset

ZS44/ZS56 Headset

Price range: $160.00 through $181.00

Stylish, durable, and easily serviceable.  Those were the goals when designing our headsets.  We machine engrave our logos for a classy look, use durable and easily replaceable Enduro stainless steel angular contact bearings, and use a “split” crown race design that you can install and remove by hand.

SKU: zs44zs56
Category:

Description

Product Details

Stylish, durable, and easily serviceable.  Those were the goals when designing our headsets.  We machine engrave our logos for a classy look, use durable and easily replaceable Enduro stainless steel angular contact bearings, and use a “split” crown race design that you can install and remove by hand.

The ZS44│ZS56 headset is designed to fit frames with tapered 44mm top/56mm bottom head tubes and tapered 1-1/2″ (40mm) fork steerers.  But nowadays with all the different headset standards available we needed to get specific so check the SHIS specs below.  SHIS?  Yep, that’s the “Standardized Headset Identification System” used to verify compatibility.

Technical Documents

Looking for more detailed technical info? Visit our Technical Documents page here.

Specs

  • 6061-T6 aluminum
  • Machine engraved logos
  • Easily replaceable Enduro stainless steel angular contact bearings
  • “Split” crown race for tool-free installation and removal
  • Stack height
    • Upper: 8mm
    • Lower: 4mm
  • Weight

Compatibility

  • A perfect match to our really sweet matching headset spacers, available separately
  • The ZS44│ZS56 headset is designed to fit frames with tapered 44mm top/56mm bottom head tubes and can accommodate tapered 1-1/2″ (40mm) fork steerers
  • The “ZS” stands for “Zero Stack” as the section of the cup that houses the top bearing sits inside of the frame’s head tube.  The “44” stands for the 44mm “skirt” that presses into the top of the head tube, and “56” stands for the 56mm “skirt” that presses into the bottom of the head tube
  • SHIS specification
    • Upper: ZS44/28.6
    • Lower: ZS5640
  • Not compatible with carbon forks that have integrated crown race seats
  • SHIS definitions on the Park Tools website: here
  • Frame/Fork specs:

    Frame upper head tube inside diameter

    		 33.9mm to 33.95mm

    Frame lower head tube inside diameter

    43.95mm to 44mm

    Fork steerer diameter top section

    28.45mm to 28.6mm

    Crown race seat diameter for “tapered 1-½”

    39.79mm to 39.85mm









Bearings

Headset Model

 Upper Bearing (inner/outer angle) Lower Bearing (inner/outer angle)

Lower Fork Race Compatibility

ZS44│EC44

 ACB3645SS 36/45 ACB6808CCSS 36/45

 1-½” (40mm)

What's In The Box

  • One headset which includes:
    • Top cap bolt
    • Top cap
    • Bearing cover
    • Upper bearing compression ring
    • Upper bearing
    • Upper cup
    • Lower cup
    • Lower bearing
    • Crown race
  • Headsets no longer include Star Nuts due to the Earth’s star nut overpopulation crisis. If you need one, they are available separately here.

FAQ

Will this headset fit my bike?

You will need to do some homework and get the SHIS specs of your frame and fork which those manufacturers will have.  See those definitions here.  Also see the “Compatibility” section on this page.  Simply telling us what model bike you have may not be enough info to go on.  Help us help you and get the specs!

Additional information

Weight N/A
Dimensions N/A
Head Tube

Top Steerer

Bottom Steerer / Crown Race

Color

, , , , , , ,
