M30

m30

For a long time square taper was king, but in recent years the development of new axle standards have redefined crank and drive train standards. We, at White Industries, answer this change by offering the MR30 cranksets.

The M30 is our mountain crank with configurations compatible with 1x, 1x Boost, or 2x chain rings. Both the TSR 1x standard and boost rings are designed  with narrow / wide tooth configurations, while the 2x utilizes our VBC, variable bolt circle, system whereby you are able to configure and choose your inner and outer ring to create the ideal gearing ratio for the type of riding you desire.  Using a 30mm aluminium spindle allows this crank set to be light yet durable. Compatible with BSA, T47, and Press Fit 30 systems, this new design brings a classic look to these modern cranks.  Available in black anodized or silver polished with options of spicing up a set with colored extractor bolts.  Chain rings are sold separately.

MADE IN U.S.A


specs


Price: $300 crank arms and spindle

Crank colors: black anodized or silver polish

Extractor colors: red, blue, pink, purple, black, gold

Crank lengths: 165mm, 170mm, 175mm, 180mm

Material: 2024 al

Weight: 575g *

Chain line:

  • 1x: 49mm
  • 1x Boost: 52mm
  • 2x: 47.5mm

Q factor: 176mm



*weight includes 175mm crank arms and spindle only
